MHz Range Crystal Oscillators
OZ Type
2.0 x 1.6 mm SMD Crystal Oscillator
FEATURE :
- Typical 2.05 x 1.65 x 0.75mm ceramic SMD package
- Tight symmetry (45 to 55%) available
- Operation voltage: 1.8V, 2.5V ,3.3V
- Tri-stae enable/disable
Overview:
- Package Size: 2.05 x 1.65 x 0.75 mm
- Freq. : 1.5 to 50 MHz
- Product Shape: SMD
- Supply Voltage: 1.8/ 2.5/3.3V
- Output level: CMOS
TYPICAL APPLICATION:
- WLAN/WiMax
- Mobile Phone
- DSC,Set-top Box,HDTV
Note: not all combination of options are available. Other specifications may be available upon request.
Specifications subject to change without notice.
